Name: BACHMANN DIO232 16-channel Digital Input/Output Module
Brand: Bachmann
SKU: BACHMANN DI232
Availability: InStock

مشخصات فنی

Specification
Brand Name	BACHMANN
Model Number	DIO232
Alternate Part Number	DIO232
Condition	100% Original
Dimensions	5.5x5.5x11.8cm
Description	Digital Input/Output Module
Weight	0.22KG
Warranty	12 Months

The DIO232 module is designed to interface with digital signals in industrial applications. It provides both input and output capabilities, allowing for the connection and control of various digital devices and sensors.

The digital input/output modules DIO216/x and DIO232 are designed for interfacing with digital control devices such as contactors, relays, pneumatic and hydraulic valves, as well as for reading signals from digital sources like sensors, photocells, or switches.

Features:

■16 or 32 digital channels

■16 channels that can be configured as either input or output

■Configurable interrupt inputs

■LED status display for each channel

■Supply voltage range: 18 to 34 VDC

■Reverse polarity protection for the supply voltage

■Cost-effective and space-saving design

■Direct wiring without additional potential rails (3-wire, available on DIO216)

■Configurable input filter (DIO232)
