Name: BACHMANN CNT204 32-bit Counter Module
Brand: Bachmann
SKU: BACHMANN CNT204
Availability: InStock

مشخصات فنی

Specification
Brand Name	BACHMANN
Model Number	CNT204
Alternate Part Number	CNT204
Condition	100% Original
Dimensions	5.5x5.5x11.8cm
Description	32-bit Counter Module
Weight	0.24KG
Warranty	12 Months

The counter module CNT204 contains four counters for single line pulse generators. Two of the channels can optionally be used as inputs for incremental encoders.

Features of the CNT204 Counter Module:

■Counter Inputs: Four inputs designed for single-line pulse generators.

■Incremental Encoder Inputs: Two channels can be configured to accept inputs from incremental encoders.

■Status Indication: Green LED indicators for each counter and initiator input.

■Encoder Power Supply: Provides power to encoders directly through the module’s connectors.

■Synchronization: Inputs can be synchronized for coordinated measurement.

■Supply Voltage Monitoring: Monitors all supply voltages for reliable operation.

■Period Measurement: Offers a resolution of 42 ns for precise period measurement.

■Differential Measurement: Measures phase shifts between channels C1 and C3 or C2 and C4 with a resolution of 42 ns.

BACHMANN CNT204 32-bit Counter Module
