SIEMENS 6ES7223-1PL32-0XB0 Digital Input/Output Module

Specification

Brand Name

SIEMENS

Supply Voltage Rated Value (DC): 24 V
Input Current from Backplane Bus 5 V DC, Max.: 180 mA
Digital Inputs from Load Voltage L+ (Without Load), Max.: 4 mA/Input, 11 mA/Relay
Power Loss, Typical: 10 W
Number of Digital Inputs: 16
Number of Digital Outputs: 16
Switching Capacity of the Outputs with Resistive Load, Max.: 2 A
Cable Length Shielded, Max.: 500 m
Permissible Potential Difference Between Different Circuits: 750 V AC for 1 Minute
IP Degree of Protection: IP20
Ambient Temperature During Storage/Transportation: -40 °C to 70 °C
Relative Humidity Operation at 25 °C Without Condensation, Max.: 95 %

Model Number

6ES7223-1PL32-0XB0

Alternate Part Number

6ES7223-1PL32-0XB0

Condition

100% Original

Dimensions

7x7.4x9.9cm

Description

Digital Input/Output Module

Weight

0.3kg

Warranty

12 Months
