SIEMENS 3SK2122-1AA10 safety relay

Name: SIEMENS 3SK2122-1AA10 safety relay
Brand: Siemens
SKU: 3SK2122-1AA10
Availability: InStock

پارت‌نامبر: 3SK2122-1AA10

توضیحات محصول

safety relay

Specification
Brand Name	SIEMENS	Number of Function Blocks Typical: 50 Insulation Voltage Rated Value: 50 V Degree of Pollution: 3 Surge Voltage Resistance Rated Value: 800 V Shock Resistance: 15 g / 11 ms Operating Frequency Maximum: 2 000 1/h Operating Temperature: -25 ... +60 °C Storage Temperature: -40 ... +80 °C Transport Temperature: -40 ... +80 °C Relative Humidity During Operation: 10 ... 95 % Air Pressure According to SN 31205: 90 ... 106 kPa Readback Time Maximum: 400 ms Control Supply Voltage Rated Value: 24 V Operating Power Rated Value: 4.5 W



Model Number	3SK2122-1AA10
Alternate Part Number	3SK2122-1AA10
Condition	100% Original
Dimensions	5x14.5x13cm
Description	safety relay
Weight	0.52 kg
Warranty	12 Months
