Schneider Electric 170AAO92100 Analog Output Module

The Schneider Electric 170AAO92100 is an Analog Output Module that is part of the Modicon Momentum automation platform. This module is used for sending analog signals from a programmable logic controller (PLC) to control external devices in industrial environments.

Key Specifications:
Product Type: Analog Output Module
Output Type: 2 analog outputs
Output Range:
4-20 mA current
0-10 V voltage
Resolution: 12-bit resolution for precise control
Accuracy: ±0.1% full-scale
Conversion Time: Fast response time for industrial control applications
Isolation: 500 V AC between channels and system ground
Power Consumption: Low power design for energy efficiency
Diagnostics: LED indicators for module status and output activity
Operating Temperature: -25 to 70°C

Mounting: DIN rail or panel mounting
Compatibility: Works with Modicon Momentum I/O bases and controllers
Application: Ideal for process control, industrial automation, and applications requiring analog signal output for control systems.
