Schneider Electric 140DAI74000 Discrete input module

The Schneider Electric 140DAI74000 is a Discrete Input Module from the Modicon Quantum series, designed for industrial automation applications. This module is used to monitor the status of discrete (binary) signals from sensors, switches, and other input devices.

Key Features and Specifications:
Product Type: Discrete Input Module
Number of Channels: 32 input channels
Input Voltage: 24 V DC
Input Type: Sink or source (configurable)
Input Current: 7 mA per channel
Response Time: 1 ms (typical)
Isolation: 500 V RMS isolation between channels and backplane
Power Consumption: 2.5 W
Diagnostics: LED indicators for channel status and module health
Mounting: Standard DIN rail mounting

Operating Temperature: -25 to 60°C
Compatibility: Fully compatible with the Modicon Quantum PLC and other modules in the Quantum series.
Applications:
Factory Automation: Ideal for monitoring the status of sensors and switches in manufacturing processes.
Process Control: Used in applications where reliable detection of on/off signals is required.
Machine Monitoring: Enables real-time feedback from equipment and systems.

Benefits:
High Density: With 32 channels, the module offers high-density input capabilities, saving space in control cabinets.
Reliable Operation: Designed for robustness in industrial environments, ensuring reliable performance over time.
This module is essential for integrating discrete input signals into the Modicon Quantum system, providing reliable monitoring and control capabilities for industrial automation applications.
