Name: PROSOFT MVI56E-GSC Enhanced Generic ASCII Serial Communication Module
Brand: Prosoft
SKU: MVI56E-GSC
Availability: InStock

مشخصات فنی

Brand Name:	PROSOFT
Model Number:	MVI56E-GSC
Alternate Part Number	MVI56E-GSC
Condition:	100% Original
Dimensions	3.5x14x14.5cm	Weight	0.26kg
Description	Enhanced Generic ASCII Serial Communication Module	Warranty:	12 Months

What's New?

MVI56E products are backward compatible with existing MVI56 products, ladder logic, and module configuration files already in use. Easily swap and upgrade to benefit from an array of new features designed to improve interoperability and enhance ease of use.

• ProSoft Configuration Builder (PCB): Microsoft Windows® -based utility software for diagnostics. Connect through the module's Ethernet port or use CIPconnect® to access troubleshooting features and functions.

• ProSoft Discovery Service (PDS): New Windows-based utility software to find and display a list of MVI56E modules on the network and to temporarily change a module's IP address to be able to connect with a module's web page.

• CIPconnect-enabled: Allows PC-to-module diagnostics from the Ethernet network through a 1756-ENxT EtherNet/IP™ module.

• Personality Card: An industrial-grade compact flash memory card storing the module’s Ethernet settings, allowing quick and easy replacement.

• LED Scrolling Diagnostic Display: 4-character, alphanumeric display, providing English messages for status and alarm data, and for processor and network communication status.

What's Different?

The MVI56E-GSC Generic ASCII Serial Communication module is configured in RSLogix™ 5000 software using the sample ladder or Add-On Instruction (AOI). It also uses ProSoft Discovery Service (PDS), ProSoft Configuration Builder (PCB), as well as all required product documentation.

• PDS is the software utility used to allow your PC to connect to the module to set a temporary Ethernet IP address. Then you can connect to the module's web page to retrieve or change the module's firmware though an Ethernet link.

• PCB is the software used to provide access to the module's diagnostic menus and application serial port communication data analyzer features.
