PROSOFT 4303-MNET-MBP Prolinx Communication Module

The PROSOFT 4303-MNET-MBP is a protocol conversion module designed to facilitate communication between Modbus TCP and EtherNet/IP networks, enabling the integration of Modbus devices into EtherNet/IP industrial automation systems with ease.

Power Supply: It operates on a nominal 24 VDC, with a range from 18 to 36 VDC allowed.

Current Load: It has a maximum current load of 500 mA at 24 VDC.
Operating Temperature: The module functions within a range of 20 to 50°C (4 to 122°F).
Storage Temperature: It can be stored in temperatures ranging from -40 to 85°C (-40 to 185°F).
Relative Humidity: It can operate in environments with a relative humidity of 5 to 95% (non-condensing).
Dimensions: The module measures 5.20 inches in height (13.2 cm), 2.07 inches in width (5.25 cm), and 4.52 inches in depth (11.48 cm).

Frequently Asked Questions
What are the main functions of the module?
Answer: The PROSOFT 4303-MNET-MBP module is a protocol gateway used to integrate Modbus Plus devices into a Modbus TCP/IP network. It provides a connection between Modbus Plus and Modbus TCP/IP, supporting both client and server modes, which makes it easy to connect to other Modbus devices (such as Modicon processors, etc.).
In which industries is it applicable?
Answer: The module is widely used in multiple industries, especially in manufacturing, oil and gas, electrical power, and food processing industries.
How can technical support be obtained?
Answer: ProSoft Technology offers comprehensive technical support. You can contact their global technical support team by phone or email. Support is available in multiple languages, including Chinese, Japanese, English, French, etc…
