PLC 1753-IF8XOF4 Analog I/O Module

Name: PLC 1753-IF8XOF4 Analog I/O Module
Brand: PLC Module
SKU: 1753-IF8XOF4
Availability: InStock

پارت‌نامبر: 1753-IF8XOF4

توضیحات محصول

Analog I/O Module

Specification
Brand Name	PLC	Response Time: ≥ 20 ms Current Consumption: max. 0.8 A (with max. load), idle current 0.4 A @ 24 V Terminal Block Torque: 0.51 Nm (4.5 in-lb) Number of Inputs: 8 Shunt Resistor, External: 500 Ω (for current input) Impedance, Analog Input: > 2 MΩ Analog Input Signal, Source Impedance: ≤ 500 Ω Input Resolution: 12 bits Effective Resolution: 9 bits @ 10 V Safety Accuracy: 2% Number of Outputs: 4 Impedance, Current Output: 600 Ω max. Storage Temperature: -40°C to +85°C (-40°F to +185°F) Operating Temperature: 0°C to +60°C (+32°F to +140°F) Enclosure Type Rating: IP20



Model Number	1753-IF8XOF4
Alternate Part Number	1753-IF8XOF4
Condition	100% Original
Dimensions	20.5x8.2x11.2cm
Description	Analog I/O Module
Weight	0.9 kg
Warranty	12 Months
