HONEYWELL FS-TPSU-2430 DC/DC converter

Specification

Brand Name

HONEYWELL

MTBF: approx. 400,000 hours
Nominal Input Voltage: 24 Vdc
Input Voltage Range: 18 to 36 Vdc
Inrush Current: ≤ 4 A
Output Voltage: 30 Vdc ± 0.25 V
Output Current: 1 A
Short-Circuit Current: < 3.3 A
Ripple (0–30 MHz): < 0.1 Vrms
Regulation: < 1% (load + line)
Switching Frequency: > 25 kHz
Isolation Voltage: Input to output 2000 Vac (1 min.)
Operating Temperature: –5°C to +70°C (23°F to 158°F)
Storage Temperature: –40°C to +85°C (–40°F to +185°F)

Model Number

FS-TPSU-2430

Alternate Part Number

FS-TPSU-2430

Condition

100% Original

Dimensions

15x7x6cm

Description

DC/DC converter

Weight

0.46 kg

Warranty

12 Months
