Name: Honeywell CC-TAON01 51306519-175 Analog Output 16pt w/o HART
Brand: Honeywell
SKU: CC-PAON01
Availability: InStock

Brand Name:	HOENYWELL
Model Number:	CC-TAON01
Alternate Part Number	51306519-175
Condition:	100% Original
Dimensions	12.7 cm x 5.1 cm x 20.3 cm	Weight	0.7kg
Description	Analog Output 16pt w/o HART	Warranty:	12 Months

The Honeywell CC-TAON01 Analog Output (AO) Module provides high-level constant current outputs to actuators and recording/indicating devices. It is designed to offer precise and reliable analog output for process control applications.

Features:
Extensive Self-Diagnostics: Monitors the module's health and provides diagnostic information.
Optional Redundancy: Allows for the addition of redundant modules to ensure continuous operation.
Configurable FAILOPT: Each channel can be configured to either hold the last value or shed to a safe value in case of failure.
Output Read-back and Alarm: Ensures that any discrepancies in output values are detected and reported.
Open-Wire Detection: Alerts to open field wires, preventing potential issues with signal transmission.

Applications:
Process Control: Suitable for applications requiring reliable analog outputs for controlling actuators or recording devices.
Automation Systems: Integrates into process automation systems where precise current output is essential.
Industrial Monitoring: Used in environments where constant monitoring and control of analog signals are necessary.
Configuration and Integration:
Mounting and Installation: Designed to fit into standard control racks or panels.
Power Supply: Operates with a standard power supply typically used in industrial control systems.
Compatibility: Integrates seamlessly with other Honeywell control systems and compatible equipment.

Parameter	Specification
Model	CC-PAON01
IOTA Models	CC-TAON01 (Non-Redundant, 6”), CC-TAON11 (Redundant, 12”)
Output Type	4-20 mA
Output Channels	16 channels
Output Ripple	< 100 mV peak-to-peak at power line frequency, across 250 Ω load
Output Temperature Drift	0.005% of Full Scale/°C
Output Readback Accuracy	±4% of Full Scale
Output Current Linearity	±0.05% of Full Scale nominal
Resolution	±0.05% of Full Scale
Calibrated Accuracy	±0.35% of Full Scale (25°C) including linearity
Directly Settable Output Current Range	0 mA, 2.9 mA to 21.1 mA
Maximum Resistive Load	800 ohms (with 24 V supply = 22 VDC through 28 VDC)
Maximum Output Compliant Voltage	16 V (with 24 V supply = 22 VDC through 28 VDC)
Maximum Open Circuit Voltage	22 V
Response Time	Settles to within 1% of final value within 80 ms
