Honeywel FS-PDC-ART05 power distribution cable
پارتنامبر: FS-PDC-ART05
توضیحات محصول
power distribution cable
مشخصات فنی
| Brand Name: | HONEYWELL | ||
| Model Number: | FS-PDC-ART05 | ||
| Alternate Part Number | FS-PDC-ART05 | ||
| Condition: | 100% Original | ||
| Dimensions |
30 cm x 3 cm x 2 cm | Weight | 0.3KG |
| Description | power distribution cable | Warranty: | 12 Months |
| | | | |
The PDC-ART05 cable is used to transfer 5V DC power and watchdog signals from CP1 or CP2 to an IO chassis in a Honeywell control system. It ensures proper power distribution and monitoring within the system.
How many pairs of PDC-ART05 cables are required for each chassis?
Each chassis requires one pair of PDC-ART05 cables. These cables connect to the CP chassis backplane in the controller cabinet.
How are the PDC-ART05 cables connected to the IO rack and PDB-ARTF05?
Each IO rack uses a pair of PDC-ART05 cables to connect with the PDB-ARTF05 as follows:
Connect WdP1.x of the PDB-ARTF05 to WdP1 of the IO rack.
Connect WdP2.x of the PDB-ARTF05 to WdP2 of the IO rack.
What specific functions does the PDC-ART05 cable support in the IO chassis?
The PDC-ART05 cable supports the distribution of 5V DC power and watchdog signals from CP1 or CP2 to the IO chassis. This ensures that the IO chassis receives the necessary power and monitoring signals.
Where can I find the distribution layout for the PDC-ART05 cable?
The distribution layout for the 5V DC and watchdog signals can be found in the Safety Manager A.R.T. documentation, which provides details on how these signals are distributed.
