HOENYWELL FC-TSAO-0220M Safe Analog Output Module
توضیحات محصول
مشخصات فنی
| Brand Name: | HOENYWELL | ||
| Model Number: | FC-TSAO-0220M | ||
| Alternate Part Number | FC-TSAO-0220M | ||
| Condition: | 100% Original | ||
| Dimensions | 5.1 cm x 15.2 cm x 7.6 cm | Weight | 0.2kg |
| Description | Safe Analog Output Module | Warranty: | 12 Months |
| | | | |
The Honeywell FC-TSAO-0220M is a Safe Analog Output Module designed for use in industrial safety and control systems. Here’s an overview of its key features and specifications:
Field termination assembly module TSAO-0220m is the interface between system interconnection cableSICC-0001/Lx and external field wiring (screw terminals). The two channels of an TSAO-0220m modulecan be connected to a (redundant pair of) SAO-0220m module(s) with the system interconnection cableSICC-0001/Lx
Key Features:
Field Termination:
Function: The TSAO-0220M module acts as an interface between the system interconnection cables (e.g., SICC-0001/Lx) and the external field wiring. This allows for a secure and organized connection between the control system and field devices.
Analog Output Channels:
Channels: Provides analog output functionality with two channels. These channels can be connected to redundant pairs of analog output modules (SAO-0220M) to ensure high reliability and system redundancy.
| Specification | Details |
| General Type Numbers | FS-TSAO-0220M, FC-TSAO-0220M |
| Approvals | CE, TUV, UL, CSA, FM |
| Power | - |
| Number of Channels | 2 |
| Maximum Voltage | 40 V DC – IEC 1010 (1990), Overvoltage Category 3 (Table D.12) |
| Maximum Continuous Current per Channel | 25 mA |
| Physical Dimensions | 50 × 70 × 48 mm (L × W × H) |
|
| 1.97 × 2.76 × 1.89 in (L × W × H) |
| DIN EN Rail Compatibility | TS32 / TS35 × 7.5 mm |
| Used Rail Length | 51 mm (2.01 in) |
| Termination | Screw terminals |
| Max. Wire Diameter | 2.5 mm² (AWG 14) |
| Strip Length | 7 mm (0.28 in) |
| Tightening Torque | 0.5 Nm (0.37 ft.-lb.) |
