HOENYWELL 8C-TDIL51 51306969-175 Digital Input 24VDC
توضیحات محصول
مشخصات فنی
| Brand Name: | HOENYWELL | ||
| Model Number: | 8C-TDIL51 | ||
| Alternate Part Number | 51306969-175 | ||
| Condition: | 100% Original | ||
| Dimensions | 5.1 cm x 15.2 cm x 7.6 cm | Weight | 0.2kg |
| Description | Digital Input 24VDC | Warranty: | 12 Months |
| | | | |
The Honeywell 8C-TDIL51 51306969-175 Digital Input module is designed to handle discrete digital inputs for industrial automation systems. Here are the key features and specifications:
Key Features and Specifications:
Part Number: 51306969-175
Module Type: Digital Input 24VDC
Functionality: Accepts 24VDC discrete signals as inputs from various field devices
Input Channels: Typically supports 8 channels for connecting multiple discrete inputs
Input Voltage: Designed for 24VDC signals
Input Type: Digital inputs for discrete on/off signals
Isolation: Provides electrical isolation to protect the control system from high voltages or transients in the field
Signal Conditioning: May include signal conditioning features to ensure accurate and reliable input signal processing
Mounting: Fits into standard Honeywell control racks or enclosures
Power Requirements: Operates on standard industrial power supplies suitable for 24VDC operation
Diagnostic Features: Includes diagnostic tools for monitoring input status and troubleshooting issues
Features:
Discrete Inputs: Handles digital signals representing binary states (on/off) from field devices such as switches or relays
24VDC Compatibility: Specifically designed to work with 24VDC signal levels
Electrical Isolation: Ensures protection against electrical noise and interference
Signal Processing: Provides reliable signal processing for accurate input readings
| Specification | Details |
| Input Channels | 32 |
| Galvanic Isolation | 1000 VAC RMS (any input terminal voltage referenced to common) |
| Isolation Technique | Optical (in IOM) |
| DI Power Voltage Range | 18 to 30 VDC |
| ON Sense Voltage/Current | 13 VDC (min) or 3 mA (min) |
| OFF Sense Voltage/Current | 5 VDC (max) or 1.2 mA (max) |
| Input Impedance | 4.2 KΩ |
| Absolute Delay Across Input Filter and Isolation | 5 ms ± 20% |
| Field Resistance for Guaranteed ON Condition | 300Ω max @ 15 VDC |
| Field Resistance for Guaranteed OFF Condition | 30 KΩ min @ 30 VDC |
