Bently Nevada 991-06-70-02-00 Thrust Transmitter

Name: Bently Nevada 991-06-70-02-00 Thrust Transmitter
Brand: Bently Nevada
SKU: 991-06-70-02-00
Availability: InStock

پارت‌نامبر: 991-06-70-02-00

توضیحات محصول

Thrust Transmitter

Specification
Brand Name	Bently Nevada	Power Requirement: +12 to +35 Vdc input at the transmitter terminal Maximum Loop Resistance: 1,000 Ω including cable at 35 Vdc Current Limiting: 23 mA typical Output Impedance: Prox Out has a 10 kΩ output impedance calibrated for a 10 MΩ load Minimum Target Size: 9.5 mm (0.375 in) diameter Operating Temperature: -35°C to +85°C (-31°F to +185°F) Storage Temperature: -51°C to +100°C (-60°F to +212°F) Transducer Case Material: AISI 303 or 304 Stainless Steel (SST)



Model Number	991-06-70-02-00
Alternate Part Number	991-06-70-02-00
Condition	100% Original
Dimensions	7.3x5.9x9.9cm
Description	Thrust Transmitter
Weight	0.46 kg
Warranty	12 Months
