Bently Nevada 330180-X1-CN MOD:163339-01 3300 XL Proximitor Sensor

Maximum Connector Torque: 0.565 N•m (5 in•lbf)
Frequency Response: 0 to 10 kHz, +0, -3 dB
Recommended Gap Setting for Radial Vibration: -9 Vdc
Probe Case Material: AISI 303 or 304 stainless steel
Extended Temperature Range Cable: 75 Ω triaxial
Minimum Cable Bend Radius: 25.4 mm
Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft)
Proximitor Sensor Material: A308 aluminum
Operating Temperature: -52°C to +100°C (-62°F to +212°F)
Storage Temperature: -52°C to +105°C (-62°F to +221°F)
