ABB PDQ22-FBP.0 1SAJ240200R0050 PROFIBUS FieldBusPlug Quad

Description：
Extended Product Type:PDQ22
Product ID:1SAJ240200R0050
Catalog Description:
PROFIBUS DP-V0/V1 FieldBusPlug Quad
Long Description:
Ready-made Profibus DP/V1 fieldbus interface for four devices. Applicable with all FBP motor starters and other terminal devices. Degree of protection IP65, diagnostic LED

Dimensions：
Product Net Width:60 mm
Product Net Depth / Length:33.5 mm
Product Net Height:0.153 mm
Product Net Weight:443 g

Technical：
Mounting Type:Single Mounting
Mounting on DIN Rail:
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Power Loss:Approximately 0.9 W
Rated Control Supply Voltage (Us):24 V DC
Standards:
CAN/CSA C22.2 No.142
IEC/EN 61131-2
UL 508
Suitable For:
UMC22
UMC100-FBP
Suitable for Product Class:Universal Motor Controllers

(FAQs) about the ABB PDQ22 1SAJ240200R0050 PROFIBUS FieldBusPlug Quad:
1. What is the ABB PDQ22 1SAJ240200R0050?
The ABB PDQ22 1SAJ240200R0050 is a PROFIBUS FieldBusPlug Quad that provides connectivity for industrial automation systems, allowing integration of multiple field devices over a PROFIBUS network.

2. How many devices can be connected to the PDQ22?
The PDQ22 features four independent FieldBus ports, enabling the connection of multiple field devices simultaneously, enhancing network flexibility.

3. What type of devices can be connected to the PDQ22?
The PDQ22 can connect a wide range of PROFIBUS-compatible devices, including sensors, actuators, and other field instruments commonly used in industrial automation.
