Name: 1746-BTM Barrel Temperature Control Module
Brand: PLC Module
SKU: 1746-BTM
Availability: InStock

مشخصات فنی

Specification
Brand Name	plc module
Model Number	1746-BTM
Alternate Part Number	1746-BTM
Condition	100% Original
Dimensions	12.7 cm x 5.1 cm x 15.2 cm
Description	Barrel Temperature Control Module
Weight	0.4KG
Warranty	12 Months

The 1746-BTM is a barrel temperature control module used in SLC 500 series systems to monitor and regulate temperature in applications such as plastic molding and extrusion.

The 1746-BTM module is compatible with any SLC processor that supports M0/M1 files, including the SLC 5/05, SLC 5/04, SLC 5/03, and SLC 5/02 controllers.

The 1746-BTM Auto Tune procedure is designed to be executed as a one-time event, during which the characteristics of the controlled system are identified and integrated into the control scheme.

To configure the 1746-BTM module to report error codes, you need to set bits 10–8 to 100 in word 192 of the output image buffer table.

What types of thermocouples are compatible with the 1746-BTM module?

The module supports standard thermocouple types, such as Type J, K, and others, commonly used in industrial temperature measurement. Specific thermocouple compatibility can be found in the product’s technical documentation.
